LF007-LF 2 1/2
Part of the LF007 Series
Ordering Code: 0063236
UPC: 098268507522
2 1/2 Inch Lead Free Double Check Valve Backflow Preventer Assembly, Less Shutoff, Single Top Entry, Epoxy Coated Using ArmorTek Technology
This 2 1/2 inch lead free double check valve backflow preventer assembly prevents the backflow of contaminated water into the potable water supply. It consists of an fused epoxy coated cast iron body using ArmorTek(TM) coating technology for advanced corrosion resistance construction that is easy to maintain and service. It is ideal at referenced cross-connections identified as non-health hazard applications. The maximum working pressure is 175 psi (12.06 bar). The coating on this backflow assembly uses ArmorTek technology to resist corrosion due to microbial induced corrosion (MIC) or exposed metal substrate.
Features
- Utilizes advanced ArmorTek coating technology to resist corrosion of internals
- The valve body shall utilize a coating system with built in electrochemical corrosion inhibitor and microbial inhibitor
- No special tools required for servicing
- Compact space saving design
- No special tools required for servicing
| Specifications | |
|---|---|
| ArmorTekTechnology | Yes |
| BuyAmericanAct | NO |
| EANUCCCode | 098268507522 |
| MaximumTemperature-Fahrenheit | 110 |
| MaximumWorkingPressure-BAR | 12.10 |
| MaximumWorkingPressure-PSI | 175 |
| MinimumTemperature-Celsius | 0.50 |
| MinimumTemperature-Fahrenheit | 33 |
| TrademarkName-Primary | None |
